Project legend
Import or configure the symbols and graphical conventions used in the P&IDs.
Ligava Insight
From P&IDs to Engineering Intelligence.
Ligava Insight analyzes P&ID PDFs and turns symbols, tags, and project information into structured data ready for review and export.
Method
First the project's language. Then the extraction.
Insight does not assume every P&ID is the same: each project is configured with its own legend and naming methodology, which become the reference for analysis.
Naming rules
Define the tagging methodology used to interpret prefixes, loops, and identifiers correctly.
P&ID analysis
Recognition of tags and components based on the project-specific rules.
Structured data
Results are organized in an internal data model rather than simply copied into a spreadsheet.
Review and confidence
Uncertain items are highlighted so human review can focus only where it is needed.
Lists and Excel
Export validated data to technical lists, starting with the I/O List, and to Excel/CSV formats.
Objective
Reduce repetitive work while keeping engineering control.
Ligava Insight is designed to accelerate data extraction from P&IDs without replacing engineering judgement. The software proposes structured data and flags uncertain cases; final validation remains transparent and reviewable.
